Powerlatch™ Chassis Connector

Powerlatch™
Chassis Connector

Part Number: IO-PRC3MPX

Powerlatch™ chassis connectors are specialized AC power connectors designed to replace common IEC bulkhead inlet and outlet connectors for a more secure connection.


UL Recognized and Approved Components​

Powerlatch™ chassis connectors are specialized AC power connectors designed to replace common IEC bulkhead inlet and outlet connectors for a more secure connection.


UL Recognized and Approved Components​

FEATURES

Strong Locking Mechanism
Rated for 20A/250V AC
Blue (A) and Gray (B) Options
Unique Keyways
Flat Tab Terminals
UL Approved Components

AVAILABLE SIZES

OVERVIEW

Powerlatch™ AC power chassis connectors are designed for single-phase AC applications and are rated for 20A at 250V AC which makes them perfect for high current applications like stage productions, lighting, or video distribution systems. As such, these connectors include several safety features to protect the user.



They utilize a twist-to-lock motion in order to provide the safest connection for high current applications by virtually eliminating the possibility of accidental unplugging while protecting the user from uninTentional shocks and conductor damage. The connectors are also specifically keyed and color coded for input (blue or A) and output (gray or B) to eliminate the possibility of intermating. Lastly, they feature a pre-mating ground contact to ensure the circuit is properly grounded before the rest of the conductors make a connection. The chassis connectors are designed to fit into standard “J” Size power receptacle locations.



Powerlatch™ chassis connectors are a perfect solution for applications where local receptacle standards differ, but safety must be maintained at all times. The sturdy, locking plastic connectors offer durability that will ensure years of reliable service without interruption or fatigue even in harsh environments. The ability to install or remove them in the field means that installers and integrators can customize their use and get the job done.



NOTE: Not to be disconnected under load.

Technical Specifications

Product

IO-PRC3MPX

part number

Male

GENDER

3

CONTACTS

MATERIAL

Phosphor Bronze

CONTACTS

Silver

CONTACT PLATING

Polyamide

SHELL

Nickel

LOCKING ELEMENT PLATING

Phosphor Bronze

LOCKING ELEMENT

Blue or Gray

SHELL FINISH

MECHANICAL

> 1000 Mating Cycles

LIFETIME

Quick Lock

LOCKING DEVICE

Front Mounting

MOUNTING DIRECTION

J Size

CHASSIS SHAPE

Flat Tab Terminals

WIRING

IPX5

Protection Grade

ELECTRICAL

≤ 3 mΩ

CONTACT RESISTANCE

2000V @ 60s

DIELECTRIC STRENGTH

≥ 100 MΩ

Insulation Resistance

25 A / 250 VAC

Current Rating

Environmental

UL 94 V-0

FLAMMABILITY GRADE

IEC 61984

UL LISTED (US)

E500108

UL LISTED (US)

-40°C ~ +70° C (-40°F ~ +158°F)

UL LISTED (US)

Technical Specifications

Product

IO-PRC3MPX

part number

Male

GENDER

3

CONTACTS

MATERIAL

Phosphor Bronze

CONTACTS

Silver

CONTACT PLATING

Polyamide

SHELL

Nickel

LOCKING ELEMENT PLATING

Phosphor Bronze

LOCKING ELEMENT

Blue or Gray

SHELL FINISH

MECHANICAL

> 1000 Mating Cycles

LIFETIME

Quick Lock

LOCKING DEVICE

Front Mounting

MOUNTING DIRECTION

J Size

CHASSIS SHAPE

Flat Tab Terminals

WIRING

ELECTRICAL

≤ 3 mΩ

CONTACT RESISTANCE

2000V @ 60s

DIELECTRIC STRENGTH

≥ 100 MΩ

Insulation Resistance

25 A / 250 VAC

Current Rating

Environmental

UL 94 V-0

FLAMMABILITY GRADE

IEC 61984

UL LISTED (US)

E500108

UL LISTED (US)

-40°C ~ +70° C (-40°F ~ +158°F)

UL LISTED (US)
